Wi-530S Submerge Type

Specifications:

  • Maximum Workpiece Size (LxWxH) – 870x540x295 mm
  • Wire Diameter Range – Ø 0.1~0.3 mm
  • Work Table Size – 740×500 mm
  • Max. Taper Angle (°)Workpiece Thickness – ±22.5 (100 mm)
  • Maximum Workpiece Weight – 700 kgs
  • Maximum Axes Load – 10 kgs
  • Drive & Servo – 5 axes AC Servo
  • Conductivity – Automatic
Categories: , ,

Product description

Specifications:

Wi-530S Submerge Type

MODEL Wi-530S
Max. Workpiece Size LXWXH                                mm 870X540X295
Work Table Size                                                          mm 740X500
Max. Working Load                                                    kgs 700
X/Y/Z Axis Travel                                                        mm 500/300/300
U/V Axis Travel                                                           mm 100/100
Wire Diameter Range                                              mm Ø 0.1~0.3
Max. Taper Angle/Workpiece Thickness      °/mm ±22.5/100
Max. Wire Load                                                            kgs 10
Water Tank Capacity                                                   L 570
Net Weight                                                                    kgs 2450
Machine Layout WXDXH                                         mm 3250X2200X2150
electric discharge machine, EDM machining, EDM electrical discharge machining, discharge machining
